Moulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile Test

Brand Name : JINHAIHU

Model Number : XWW-10KN

Certification : ISO9001

Place of Origin : BEIJING, CHINA

MOQ : 1 set

Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P

Supply Ability : 20 sets per month

Delivery Time : 7 work days

Packaging Details : Standard export wooden cases

Place of origin : Beijing, China

Customized support : OEM, ODM, OBM

Product Name : Universal test machine/Determination of tensile properties for moulding and extrusion plastics

Capacity : 10KN

Model : XWW-10KN

Application : PVC, PE, ABS, PP, PMMA, PC, RAHECO, etc

Accuracy range : ±0.5%

Certificate : ISO, CE

Power : 220V, 50HZ(can customized)

Warranty : 12 months

Contact Now

Universal test machine/Determination of tensile properties for moulding and extrusion plastics

Application:

Universal test machine/Determination of tensile properties for moulding and extrusion plastics is used to test the mechanical properties of various materials such as static load, tensile, compression, bending, shearing, tearing, peeling and other mechanical properties of mechanical equipment. It is suitable for plastic plates, pipes, and other materials. Various physical and mechanical performance tests of profiles, plastic films and rubber, wires and cables, steel, fiberglass and other materials are developed for materials.

Meet Standards:

ISO 527, ISO 6259, GB/T 1040, ISO7500-1, ISO 5893,ISO 9969, ASTM D638695790

Software function:

Auto zero set. Max force, upper-yield strength, lower-yield strength, anti-tensile intensity anti-compression strength, elasticity modulus, percentage of elongation, etc. are calculated automatically.

Main technical parameters

Model XWW-10KN
Type Double column model
Accuracy Grade Class 1 (Class 0.5 optional)
Force-measuring Range 1%~100%FS(0.4%~100%FS optional)
Deformation-measuring Range 2%~100%FS
Deformation-measuring Accuracy ±1%
Crossbeam Displacement Resolution 0.001mm
Crossbeam Speed Range 0.05~500mm/min
Displacement Speed Accuracy ≤ ±0.5%
Metal Extensometer Accuracy Grade ±0.5%
Test width 380mm
Tensile Space 700mm
Compression Space 1000mm
Clamps Tensile, compression, bending fixture
PC System Equiped with brand computer
Power Supply AC 220V±10%, 50Hz (can be customized as customer request)
Size of the host 700*400*2000mm
Packing size & Weight 800*500*2100mm,about 350kg

Moulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile Test

Moulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile TestMoulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile TestMoulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile Test

Moulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile TestMoulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile Test

Moulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile TestMoulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile TestMoulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile Test

Moulding And Extrusion Plastics 10kn Electronic Universal Testing Machine Tensile Test
